AI Function and Intelligent Learning
Equipped with the latest AI-powered barcode positioning technology, the NLS-NVH220 improves decoding performance for low-contrast barcodes. Additionally, intelligent learning enables automatic parameter adjustments based on different scenarios.
Advanced Illumination System
Provides red and blue direct illumination and white diffuse lights. The versatile lighting system accommodates various materials (such as reflective surfaces), shapes (such as curved surfaces), backgrounds, and barcode colors, meeting diverse and complex scanning requirements.
Excellent DPM Decoding Capability
Featuring the latest UlMG decoding system, it enhances decoding success rates for complex barcodes, optimizing workflows and improving overall decoding efficiency. It also delivers exceptional decoding performance for DPM barcodes, including laser-etched and dot-peened markings.
High Protection Industrial Structure Design
The NLS-NVH220-HD, built into an IP64-sealed and can withstand repeated falls from 1.8 meters to the ground, with excellent reliability and stability.
Upgraded Dual-Core Processing Platform
The NLS-NVH220 features an upgraded dual-core processing platform that enhances computing capability and efficiency, enabling faster, more stable decoding with lower power consumption.
| Technical Specifications | |
| Input Voltage | 5VDC+/-5% |
| Motion Tolerance | 2m/s |
| Operating Current | Operating (typical) 300mA <br> Operating (max.) 450mA |
| Scanning Angle | Roll: 360deg, Pitch: +/-50deg, Skew: +/-50deg |
| Sensors | Image sensor: 1280 x 800 CMOS |
| Light Source | Direct: red & blue LEDs; Diffuse: white LED; |
| Depth of Field | EAN-13(13mil) : 10mm-280mm<br> Code 39(5mil) : 30mm-180mm<br> Code 39(20mil) : 50mm-440mm<br> Data Matrix(10mil) : 15mm-140mm<br> QR Code(20mil) : 10mm-250mm |
| Interface | USB, RS232 |
| Resolution | >= 3mil(2D)<br> >=1.85mil(1D) |
| YTVideo | |
| YTid | cpiGeobiB4E |
| Links | |
| Datasheet | https://d1bx683snmhtki.cloudfront.net/BarcodeScanner/NVH220/NLS-NVH220-HD_Datasheet_en.pdf |
| Quick Guide | https://d1bx683snmhtki.cloudfront.net/BarcodeScanner/NVH220/NLS-NVH220_User_Guide.pdf |
