• The unique RFID antenna and pioneering RFID module ensure accurate printing and encoding, as well as enabling a 12mm minimum inlay space.
  • Innovative design on label detection fixes the antenna on the tear-off position. Since each finished label goes through the printhead, it can be read to detect defective labels.
  • Advanced design allows printing on labels without a margin, resulting in no wasted white space, hence a total print cost savings.
  • User-friendly design ensures convenience and proficiency by allowing automatic label size calibration and the ability to easily adjust the antenna position through the setup menu.

  • Printing Method Thermal Transfer Printing Resolution 203 dpi Max Printing Speed 10 ips (254 mm/s)  Max Printing Width 4.09″ (104 mm) Max Printing Length 157″ (4000 mm) RFID Integrated UHF Reader/Encoder, EPC Gen 2 Class1 / ISO 18000-6C Memory 8 MB FLASH ROM, 16 MB SDRAM HEAT™ Level Ⅱ Media

    Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain paper or  thermal paper.
    Width: 4.56″ (116 mm) max., 0.39″ (10 mm) min.
    Supply roll: OD 8″ (203.2 mm) max., ID 1.5″ (38 mm) min.
    Thickness: 0.0024″ - 0.012″(0.06 - 0.305 mm), including liner.


    Wax, Wax/Resin, Resin
    Ribbon roll: OD 3.3″ (84 mm) max., ID 1″ (25.4 mm) core
    Max width: 118 mm; Max length: 600 m.
    Ink side: Both In & Out

    Media Sensor Up & Down Reflective (Adjustable) / Transmissive (Adjustable) Fonts Five built-in dot martrix  ASCII fonts, Downloadable TrueType fonts Barcode Types 1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E 2
    and 5 add-on, EAN-13/8/128, UCC-128;
    2D Barcode: MaxiCode, PDF417, Datamatrix, QR Code. Interfaces RS-232 Serial, 10/100 M-bit Ethernet, USB DEVICE 2.0, USB Host, Centronics Parallel Power Rating 110/240 VAC±10%, 50/60 Hz Weight 15 kgs Dimensions W 286 mm x D 448 mm x H 280 mm Operating Environment Temperature: 0℃ – 40℃ (32°F ~ +104°F); Relative humidity: 5% - 85% non condensing Storage Environment Temperature: -40℃ – 60℃ (-40°F ~ +140°F); Relative humidity: 5% - 85% non condensing Optional Items Rotary Cutter, External Rewinder,
